Circulation pump 25-80 180 0301W Weberman/IBO
€82.28
Manufacturer
Weberman
Model
Weberman 0301W
.jpg)
| model | 25-80 |
| action | -10.5 m ³/h 0.1 |
| lifting | Max. 8 m |
| fluid temperature | min + 2 ° C + 110 ° C, max. |
| liquid type | clean, with no solid or oily mineral substances, not the co, chemically neutral, with parameters close to that of water |
| maximum pressure | 10 bar |
| class of protection | IP 44 |
| insulation class | (H) |
| choke cable | PG 9 |
| System | axl is shaft in a horizontal position, the terminal box located anywhere except under the pump |
| voltage | 50-60 Hz, ~ 230V |
| Consumption can (I, II, III) | 135/190/245 W |
| distance | 180 mm |
| input | G 1 1/2 " |
| The ambient temperature | min + 2 ° C + 40 ° C, max. |
