Circulation pump 25-80 180 0301W Weberman/IBO

€82.28
Manufacturer
Weberman
Model
Weberman 0301W
+
model 25-80
action -10.5 m ³/h 0.1
lifting Max. 8 m
fluid temperature min + 2 ° C + 110 ° C, max.
liquid type clean, with no solid or oily mineral substances, not the co, chemically neutral, with parameters close to that of water
maximum pressure 10 bar
class of protection IP 44
insulation class (H)
choke cable PG 9
System axl is shaft in a horizontal position, the terminal box located anywhere except under the pump
voltage 50-60 Hz, ~ 230V
Consumption can (I, II, III) 135/190/245 W
distance 180 mm
input G 1 1/2 "
The ambient temperature min + 2 ° C + 40 ° C, max.
